CK5263E Series CNC Heavy-Duty Double Column Vertical Lathe

Payment Terms:	T/T
Place of Origin:	Shandong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: CK5263E

Production Capacity: 10PCS/YEAR

Delivery Date: a month

Raw Material: Steel Bar

Certification: CE

Brand Name: GRANDWILL

Means of Transport: Ocean,Land

Packing: as per buyer's requirement

Power: Cnc

Automation: Automatic

Material / Metal Processed: Stainless Steel

CK5263E Series CNC Heavy-Duty Double Column Vertical Lathe is high-tech mechanically and electrically integrated lathe manufactured with optimal CAD d

CK5263E Series CNC Heavy-Duty Double Column Vertical Lathe is high-tech mechanically and electrically integrated lathe manufactured with optimal CAD design, cutting-edge technology and advanced functional parts.

Features

1. Extremely powerful cutting capability;

2. Handling extremely heavy load;

3. Higher dynamic stiffness & higher static stiffness;

4. Longer life time;

5. Higher machining efficiency.

Specifications

Worktable Diameter	Φ5700 mm
Max. Turning Diameter	Φ6300 mm
Max. Turning Height	4000 mm
Max. Weight of Workpiece	100,000 kg
Worktable Speed	0.4~40 rpm
Max. Torque of Worktable	200 knm
Toolpost Feed Speed	0.1-1600 mm/min
Ram Travel (Z)	2000 mm
Main Motor Power	75 kw
Approximate Weight	150,000 kg
